The Ford 1320 is a 2WD or 4WD compact utility tractor from the Twenty Compact series. This tractor was manufactured by Shibaura for Ford in Japan from 1987 to 1998. The Ford 1320 is equipped with a 1.3 L three-cylinder diesel engine and one of two transmissions: gear type transmission with 9 forward and 3 reverse gears or hydrostatic transmission with infinite forward and reverse.
The Ford 1320 compact utility tractor used the Shibaura J823 engine. It is a 1.3 L, 1,266 cm2, (77.3 cu·in) three-cylinder natural aspirated diesel engine with 82.0 mm (3.23 in) of the cylinder bore and 80.0 mm (3.15 in) of the piston stroke. The compression ratio rating is 22.0:1. This engine produced 20.3 PS (14.9 kW; 20.0 HP) at 2,500 rpm of output power.
FORD 1320 Production Details. Manufactured by: FORD. Years Made: 1987-1998. Price at production date: $12,145.00. FORD 1320 Horsepower. Ford Shop Manual Models 1120 1220 1320 1520+ (Manual Fo-46) FO46 Ford Tractor Service Manual Diesel Models: 1120, 1220, 1320, 1520, 1720, 1920, 2120 MORE. Mover Parts 3PCS Glow Plug for Ford Tractor 1100 1110 1120 1200 1210 1215 1220 1300 1320 1510 1530 1620 1630 1710 1715 1720 1725 1910 1925 1990 2110 3412. The Ford 1320 is a 2WD or 4WD compact utility tractor from the Twenty Compact series. This tractor was manufactured by Shibaura for Ford in Japan from 1987 to 1998. The Ford 1320 is equipped with a 1.3 L three-cylinder diesel engine and one of two transmissions: gear type transmission with 9 forward and 3 reverse gears or hydrostatic transmission with infinite forward and reverse.
The Ford 1320 is equipped with power steering, wet disc brakes, open operator station with two-post ROPS and 27.0 liters (7.1 US gal.; 5.9 Imp. gal) fuel tank.
Following attachments are available for the Ford 1320 compact utility tractor:
- Mid-mount Ford 914: 60 in (1,520 mm) mower deck
- Front-mount Ford 702C: 78 in (1,980 mm) blade
- Front-mount Ford 715A: 63 in (1,600 mm) snowblower
- Ford 7108 loader
- Ford 757B backhoe
Ford 1320 Specifications
| General Specifications | |
| Model | Ford 1320 |
| Length | 2,850 mm (112.2 in) |
| Width | 1,490 mm (58.7 in) |
| Height | 2,090 mm (82.3 in) |
| Wheel base | 1,600 mm (63 in) |
| Weight | 2WD: 960 kg (2,115 lbs) 4WD: 1,010 kg (2,230 lbs) |
| Fuel tank capacity | 27.0 liters (7.1 US gal.; 5.9 Imp. gal) |
| Battery | 12V |
| Cabin type | Open operator station with two-post ROPS |
| Engine | |
| Engine model | Shibaura J823 |
| Engine type | Four-stroke, liquid-cooled, inline |
| Cylinders | 3 |
| Fuel type | Diesel |
| Displacement | 1.3 L, 1,266 cm2, (77.3 cu·in) |
| Bore and stroke | 82.0 mm X 80.0 mm (3.23 in X 3.15 in) |
| Compression ratio | 22.0:1 |
| Horsepower | 20.3 PS (14.9 kW; 20.0 HP) at 2,500 rpm |
| Starter | Electric |
| Injection timing | 20-21° BTDC |
| Injector opening pressure | 1,705 psi (11,760 kPa) |
| Oil capacity: | 4.5 L (4.8 US. qt, 4.0 Imp. qt.) |
| Coolant capacity: | Gear transmission: 4.0 L (4.2 US. qt, 3.5 Imp. qt.) Hydro transmission: 5.0 L (5.3 US. qt, 4.4 Imp. qt.) |
| Intake/Exhaust valve clearance | 0.20 mm (0.008 in) |
| Transmission and chassis | |
| Chassis | 4×2 2WD or 4×4 MFWD 4WD |
| Steering type | Power |
| Brakes | Wet disc |
| Transmission model | – |
| Transmission type | Gear type |
| Gears | 9 forward and 3 reverse |
| Transmission model | – |
| Transmission type | Hydrostatic |
| Gears | Infinite forward and reverse |
| Tires | |
| Front tires | Ag: 6.50-10 (2WD), 6-12 (4WD) |
| Rear tires | Ag: 12.4-16 |
1320 Ford Tractor Repair Manual
| Three-Point Hitch | |
| Caterogy | I |
| Control type | – |
| Lift capacity (at 610mm/24 in) | 790 kg (1,740 lbs) |
| PTO (Power take-off shaft) | |
| Middle PTO type | Optional |
| Middle PTO speed | 2,000 rpm |
| Rear PTO type | Transmission or live (option) |
| Rear PTO speed | 540 rpm |
| Hydraulic system | |
| Hydraulic type | Open center |
| Pump flow | 6.4 gpm (24.2 lpm) |
| Steering flow | 2.8 gpm (10.6 lpm) |
| Total flow | 9.2 gpm (34.8 lpm) |
